SuperMicro SuperServer SYS-1027R-WRF (Black), 1 U, Intel® Xeon® processor E5-2600, Sandy Bridge 8C E5-2650 2.0G 20M 8GT/s QPI, 8GB DDR3-1333 2Rx4 ECC REG RoHS x 2und, Seagate 2.5” 1TB SATA 7.2K RPM 64M x 4unds ** SATA **, 3 años de Garantías


Supermicro - Super Servers 1U - 3 AÑOS GARANTÍA - DISCO SATA - TOTALMENTE CONFIGURABLE

1. Intel® Xeon® processor E5-2600
    family; QPI up to 8GT/s

2. Up to 512GB DDR3 1600MHz ECC
    Registered DIMM; 16x DIMM sockets

3. Add on card support: 2x PCI-E 3.0 x16
    Full-heigh, Half-length slots

4. Intel® i350 Dual port Gigabit Ethernet
    Controller; 2x LAN ports

5. 8x Hot-swap 2.5" SATA HDD
    bays for Customizable Storage

6. 700W Redundant Power Supplies
    80 PLUS, Gold Level Certified


Servidor SYS-1027R-WRF , SuperServer 1027R-WRF (Black)  x 1 und
CPU  DPE52650-SR0KQ  Sandy Bridge 8C E5-2650 2.0G 20M  8GT/s QPIx 1 und
Memoria   DR380L-SL06-ER13   8GB DDR3-1333 2Rx4 ECC REG RoHS x 2 unds
HDD-2T1000-ST91000640NS   Seagate 2.5” 1TB SATA 7.2K RPM 64M x 4 unds

Servidor:  http://www.supermicro.com/products/system/1U/1027/SYS-1027R-WRF.cfm
MBD:       http://www.supermicro.com/products/motherboard/Xeon/C600/X9DRW-iF.cfm








High Performance SuperServers®
The Foundation of a Flexible and Efficient Enterprise IT Environment
Supermicro’s all-star lineup of mainstream serverboards and servers includes models for every need. Performance
enhancements over previous generations of systems for these Xeon® Processor E3 and E5 Family based servers and
serverboards include up to 8 cores per CPU / 16 threads, extra memory capacity with four channels per CPU for up to 768GB of
Reg. ECC DDR3-1600MHz memory, and two QPI links running at up to 8 GT/s each. Extra enhancements include the option
of either SATA 3.0 or SAS 2.0 (6Gbps) HDDs for full-bandwidth I/O, Quad GbE or Dual 10 GbE LAN, PCI-E 3.0, upgraded
fans with highly effective cooling architecture, and redundant Platinum Level power supplies. With Supermicro’s signature
quality and support, customers will benefit from more processing capacity in less space with better efficiency and cost profiles.
Based on the Intel® Xeon® Processor E5-2600/2400 series and E3-1200 v2 family, these UP and DP Mainstream servers are the
best choices for Enterprise, Hosting and Data Center applications.


Product SKUs
SYS-1027R-WRF
  • SuperServer 1027R-WRF (Black)

Motherboard

Super X9DRW-iF

Processor/Cache
CPU
  • Intel® Xeon® processor E5-2600 (up to 130W TDP)
  • Dual Socket R (LGA 2011)
Cache
  • Up to 20MB
System Bus
  • QPI up to 8 GT/s

System Memory
Memory Capacity
  • 16x 240-pin DDR3 DIMM sockets
  • Supports up to 512 GB DDR3 ECC Registered memory (RDIMM)
  • Supports up to 192 GB DDR3 ECC Un-Buffered memory (UDIMM)
Memory Type
  • 1600/1333/1066/800MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
DIMM Sizes
  • 32GB, 16GB, 8GB, 4GB, 2GB, 1GB
Memory Voltage
  • 1.5 V, 1.35 V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)

On-Board Devices
Chipset
  • Intel® C602 Chipset
SATA
  • SATA 2.0 3Gbps with RAID 0, 1, 5, 10
  • SATA 3.0 6Gbps with RAID 0, 1
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • Renesas SH7757 BMC
Network Controllers
  • Intel® i350 Dual Port Gigabit Ethernet Controller
  • Virtual Machine Device Queues reduce I/O overhead
  • Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
  • 1x Realtek RTL8211E PHY (dedicated IPMI)
Graphics
  • G200 (Renesas SH7757 BMC)

Input / Output
SATA/SAS
  • Customizable storage
LAN
  • 2x RJ45 Gigabit Ethernet LAN ports
  • 1x RJ45 Dedicated IPMI LAN port
USB
  • 6x USB 2.0 ports total
    (4x rear + 2x via header)
VGA
  • 1x VGA port
Serial Port / Header
  • 1x Fast UART 16550 port / 1 Header




Chassis
Form Factor
  • 1U Rackmount
Model

Dimensions
Width
  • 17.2" (437mm)
Height
  • 1.7" (43mm)
Depth
  • 23.5" (597mm)
Gross Weight
  • 46 lbs (20.9kg)
Available Colors
  • Black

Front Panel
Buttons
  • Power On/Off button
  • System Reset button
  • UID button
LEDs
  • Power status LED
  • HDD activity LED
  • 2x Network activity LEDs
  • Universal Information (UID) LED

Expansion Slots
PCI-Express

Drive Bays
Hot-swap
  • 8 Hot-swap 2.5" SAS / SATA HDD trays (ready for PCI-E storage controller card)

Peripheral Drives
DVD-ROM
  • Slim DVD-ROM drive (optional)

Backplane
SAS/SATA HDD Backplane
(SAS support requires optional SAS controller)

System Cooling
Fans
  • 5x 4cm Counter-rotating PWM Fans

Power Supply
700W/750W Redundant AC-DC high-efficiency power supply with PMBus and I2C
AC Voltage
  • 700W: 100 - 140 V, 50-60 Hz, 8.5-6 Amp
  • 750W: 180 - 240V, 60-50 Hz, 5-3.8 Amp
DC Output +5V standby
  • 3 Amp
DC Output +12V
  • 700W: 58 Amp @ 100-140V
  • 750W: 62 Amp @ 180-240V
With Power Distributor
  • +5V: 25 Amp
  • +3.3V: 25 Amp
  • -12V: 0.6 Amp
Certification 80 PLUS   80PLUS Gold Certified

System BIOS
BIOS Type
  • 128Mb SPI Flash EEPROM with AMI BIOS
BIOS Features
  • Plug and Play (PnP)
  • APM 1.2
  • PCI 2.2
  • ACPI 1.0 / 2.0 / 3.0 / 4.0
  • BIOS resuce hot keys
  • USB Keyboard support
  • SMBIOS 2.3
  • UEFI

Operating Environment / Compliance
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
       5°C to 35°C (41°F to 95°F)
  • Non-operating Temperature:
       -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)



Parts List - (Items Included)
  Part Number Qty Description
Motherboard / Chassis MBD-X9DRW-iF
CSE-113TQ-R700WB
1
1
Super X9DRW-iF Motherboard
1U Chassis
Backplane BPN-SAS-113TQ-O-P 1 BPN-SAS-113TQ-O-P
Cable 1 CBL-0288L-01 1 70/60/50/50CM, W/ 70CM SB, RA ,30AWG
Cable 2 CBL-0388L-01 1 30AWG Ipass to 4SATA 90/90/70/70CM W/ 70CM SB, RA
CD CDR-X9 1 Driver CD for X9 series
Riser Card RSC-R1UW-2E16-O-P 1 RSC-R1UW-2E16-O-P
Heatsink / Retention SNK-P0047PS 2 1U Passive CPU Heat Sink for X9 Generation Motherboards w/ Narrow ILM
Power Supply PWS-704P-1R 2 1U REDUNDANT PWS PMBUS GOLD EFFICIENCY 54.5MM
Optional Parts List
  Part Number Qty Description
Storage Controller Card(s) (PCI-E Only) - - Please refer to our Storage Add-on Card Table
Network Card (PCI-E Only) - - Please refer to our Network Add-on Card Table
DVD-ROM / DVD-RW DVM-PNSC-DVD-SBT1
DVM-TEAC-DVD-SBT1
DVM-PLDS-DVDRW-SBT2
DVM-TEAC-DVDRW-SBT1
1 SLIM DVD-ROM / DVD-RW SATA DRIVE
DVD-ROM Accessory MCP-220-81502-0N 1 Slim SATA DVD kit
Internal 2.5" HDD Tray (DVD Slot) MCP-290-00036-0B 1 Black DVD dummy tray support 1x 2.5" HDD
Cables for on-board SATA2 connection CBL-0206L
CBL-0227L
CBL-0157L
CBL-0288L-01
2
2
2
1
48CM SATA Cable ROUND S-S
48CM SATA Cable ROUND S-RA
8pin to 8pin ribbon cable with tube for SGPIO, 40cm
IPASS to 4 SATA Cable, 30AWG 70/60/50/50CM, W/ 70CM SB, RA





Expandible a:








Número del Producto: SYS-1027R-WRF
Nuestro Precio: Usd.6,575.00

Cantidad:
Extensión de Garantía:
